Manual-lift design
Pull the unit up for access and retract it when the connections are no longer required.
Product guide
Compact manual-lift pop-up outlet with two AU power outlets, one USB-A port and two USB-C ports, finished with a silver top and body with black outlets.
Features
Key functions and connections at a glance.
Power and charging
Two AU power outlets, one USB-A port and two USB-C ports.
Up to 30W USB-C
Either USB-C port supports up to 30W; the USB-A port supports up to 18W.
Installation planning
Confirm the controlled opening dimensions, below-surface space and power connection before cutting the benchtop.
90mm nominal opening
Plan a 90mm nominal opening and trial-fit the actual unit before permanent cutting. No formal cutout tolerance is published.
340mm below-surface space
Allow 340mm below the top surface for the unit, with additional room for the lead and plug.
Fitted AU plug
Supplied with a 1.8m lead and fitted AU plug for connection below the benchtop.
Important: Keep the unit, plug and power connection dry. Do not exceed 10A / 2400W total, and use a licensed electrician for any electrical alteration.
Specifications
Use these details with the supplied instructions and the rating label on the product.
Electrical
240V AC, 50Hz; 10A and 2400W total maximum.
Charging
USB-C 1 / USB-C 2: up to 30W each. USB-A: up to 18W. Multiple-port output: 5V / 3A shared.
Model and finish
Model V1SC; silver top and body with black outlets; 24-month warranty.
Downloads and support
Request the latest controlled cutout drawing before fabrication.
Current cutout information
90mm nominal opening; no formal cutout tolerance is published. Allow 340mm below the top surface, plus room for the lead and plug.
Contact support (opens in a new tab)
Product and installation support
Installation uses a 90mm nominal opening, 340mm below-surface space and a fitted 1.8m AU lead and plug.
Contact support (opens in a new tab)
Frequently asked questions
What opening is required?
Plan a 90mm nominal opening and trial-fit the actual unit before permanent cutting. No formal cutout tolerance is published.
How many USB ports are included?
One USB-A port and two USB-C ports. Either USB-C port supports up to 30W when used on its own.
Does it need hardwiring?
No hardwiring is required for normal installation because the unit has a fitted AU plug. Use a licensed electrician for any electrical alteration.
Beautifully seamless
A compact and sturdy manual-lift retractable power socket
Plug and play
A single 1.8m cable plugs into a AU wall socket.
Use as specified
For indoor benchtop use. Follow the supplied instructions, keep connections dry and do not exceed the product rating.
90mm nominal opening
Plan a 90mm nominal opening and trial-fit the actual unit before permanent cutting.
Maximum output
10A, 240V AC, 50Hz and 2,400W maximum total load. USB-C supports up to 30W.
Current technical sheet
90mm nominal opening; allow 340mm below the top surface, plus room for the lead and plug.
