Matching countertop insert
The supplied top cup is empty and designed for a matching 93mm piece of the countertop or benchtop.
Product details · Model PPMBT
The Point Pod Boardroom integrates a versatile power outlet system into office and boardroom tables, providing a variety of ports with seamless tabletop integration.
This innovative system includes two USB ports (one USB-A and one USB-C), two Australian power outlets, an RJ45 data outlet, and an HDMI outlet. Its sleek design allows you to customise its appearance by inserting a cut-out of your countertop material into the top of the unit. With the push of a button, an electric motor smoothly raises the Point Pod for quick and convenient access.
Wide Range of Ports
The Point Pod Boardroom simplifies connectivity in offices, conference rooms, meeting spaces, and shared work environments. Its comprehensive port selection supports power, video, and data needs. Video and data ports operate as passthrough connections, with alternate ports located on the underside of the unit. The power outlets, however, connect directly via a single 240V cable and plug, delivering reliable power to your devices.
Point Pod at a glance
The opening, retained insert, clear space below and power connection are organised together so customers and fabricators can plan with confidence.
The supplied top cup is empty and designed for a matching 93mm piece of the countertop or benchtop.
Press the top once to raise or lower the unit and bring its connections within reach.
Two AU power outlets, one USB-A port, one USB-C port, HDMI and RJ45 passthrough.
The unit may extend upward, downward or sideways. Keep every receptacle face vertical—never facing upward.
Plan the 102mm installation opening and 93mm top insert together.
Allow 600mm of clear depth below, including room for the lead and plug, plus any surrounding services.
The fitted 1.9m AU lead plugs into a suitable accessible receptacle below the benchtop.
Important: Keep every receptacle face vertical and complete the installation in accordance with the supplied instructions and local requirements.
Check the hole size, benchtop thickness and the space needed below before you install. Select the drawing to open it full size.
(opens full size in a new tab)
See it installed, and how it copes with everyday kitchen mess.
Every Point Pod comes with a 24-month warranty, and you can extend it to 4 years. See how. Questions? Email contact@
Dimensions and details
Core product and installation information is consolidated here, while the full cutting guide remains open on the page.
Point Pod Boardroom w/USB, RJ45, HDMI. Silver finish; motorised one-touch lift; IP44 for indoor use.
Two AU power outlets, one USB-A port, one USB-C port, HDMI and RJ45 passthrough.
Opening: 102mm. Top insert: 93mm. Clear depth below: 600mm. Mounting-flange diameter: 160mm.
240V AC, 50Hz; 10A / 2,400W maximum total load. Fitted AU plug and 24-month warranty.
One page for this model: dimensions, space needed below the benchtop, electrical ratings and installation steps.
Installation, use and care information for the 102mm Point Pod range.
What to plan before an office fitout: table thickness, cable runs, floor boxes and HDMI.
Fixes for common problems, which glue to use and where to find the outer collet.
Include the model, order number and installation details when requesting assistance.
Delivery times vary by location. View Australian delivery options and estimated timeframes.
No. The top cup is supplied empty and is designed for a matching 93mm piece of the countertop or benchtop. Finished inserts may be available separately by email request at additional cost.
Yes. It may extend upward, downward or sideways, provided every receptacle face remains vertical and never faces upward.
Plan the 102mm opening and 93mm insert together. When using a hole saw, make a trial cut in matching off-cut material before cutting the finished surface.
The fitted AU plug does not require hardwiring for normal installation. Use a licensed electrician for any electrical alteration.
Spare parts
Lost or damaged a part? Order a genuine replacement and fit it yourself in minutes.
